ARCTIC P12 Pro – Powerful Premium Fan, 120 mm PWM Fan, 600-3000 RPM, 0 RPM
Price: $8.49
(as of Feb 01, 2026 10:57:14 UTC – Details)
Product description
Maximum Performance, Redefined
Revised fan blade design for an optimal balance of performance and quiet operation.
Optimized Bearing-Shaft Design (FDB)
Hydrodynamic plain bearing and extended impeller shaft – for better pressure distribution and reduced vibration, enabling particularly smooth operation.
SOTA microcontroller
Reduces motor noise and automatically compensates for speed drops due to increased resistance. Integrated protection mechanisms limit inrush current peaks and reliably protect against damage caused by reverse polarity.
Minimal gaps for maximum efficiency
Narrower manufacturing tolerances and gaps allow the fan to work more effectively against resistance, maximizing static pressure and airflow efficiency.
More Power – Less Noise
The fan impresses with a significant increase in performance even at low speeds. Normalized to 25 dB(A), the fan offers both increased airflow and increased static pressure – ideal for quiet and efficient cooling.
The high static pressure makes Pro fans ideal for use on radiators, as they can effectively move air through tight obstacles. Pressure-optimized fans are also particularly suitable for use with perforated panels or mesh fabrics, which create additional resistance.
Technical Data
Speed 600–3000 rpm (PWM controlled), 0 rpm below 5% PWM Airflow 77 cfm | 131 m³/h Static pressure 6.9 mmH₂O Fan bearing Hydrodynamic sleeve bearing Typical Voltage 12 V DC Start-up Voltage 3.3 V DC Current 0.33 A Cable Length 400mm Connector 4-pin Fan Connector Operating ambient temperature 0–40 °C Dimensions 120 (L) x 120 (W) x 25 (H) mm Weight 183 g
P12 Pro Series in Comparison
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Add to Cart
Customer Reviews
4.6 out of 5 stars 357
4.6 out of 5 stars 270
4.7 out of 5 stars 4,795
4.7 out of 5 stars 4,273
4.6 out of 5 stars 2,947
4.5 out of 5 stars 2,625
Price
$8.49$8.49
$12.49$12.49
$8.49$8.49
$9.89$9.89
$9.99$9.99
—
Fan Speed
600–3000 rpm (PWM controlled)
600–3000 rpm (PWM controlled)
1800 rpm
200–1800 rpm (PWM controlled)
200–2100 rpm (PWM controlled)
400–3300 rpm (PWM controlled)
Airflow
77 cfm | 131 m³/h
77 cfm | 131 m³/h
56,3 cfm | 95,7 m³/h
56,3 cfm | 95,7 m³/h
34,51 cfm | 58,62 m³/h
81,04 cfm | 137,69 m³/h
Fan Bearing
Hydrodynamic Bearing
Hydrodynamic Bearing
Hydrodynamic Bearing
Hydrodynamic Bearing
Hydrodynamic Bearing
Hydrodynamic Bearing
Static Pressure
6,9 mmH₂O
6,9 mmH₂O
2,2 mmH₂O
2,2 mmH₂O
1,33 mmH₂O
4,35 mmH₂O
Cable Length
400mm
400mm
400mm
400mm
400mm
400mm
Fan Connector
4-pin Connector
4-pin Connector
4-pin Connector
4-pin Connector
4-pin Connector
4-pin Connector
A-RGB LEDs
/
12x A-RGB Gen2 LEDs
/
/
/
/
RGB Connector
/
3-Pin-A-RGB-Stecker
/
/
/
/
Dimensions
120 x 120 x 25 mm
120 x 120 x 25 mm
120 x 120 x 25 mm
120 x 120 x 25 mm
120 x 120 x 25 mm
120 x 120 x 25 mm
Weight
183 g
185 g
139 g
145 g
85 g
184 g
HIGH STATIC PRESSURE: Efficient even with resistance – the generated airflow easily penetrates dense radiators, narrow perforated panels and mesh structures and ensures reliable cooling
PWM CONTROL WITH WIDE SPEED RANGE: The speed can be progressively adjusted up to 3000 rpm via the 4-pin PWM connection – the fan stops completely at less than 5% PWM
PRECISE MANUFACTURING FOR MAXIMUM SMOOTH RUNNING: Minimal gaps, automatic balancing and high-precision measurement noticeably reduce vibrations – for quiet, efficient and long-lasting performance
SMOOTH-RUNNING FLUID DYNAMIC BEARING (FDB): The self-lubricating bearing minimizes noise during operation – ideal for quiet, efficient cooling and a long, reliable service life
NEW FAN BLADE DESIGN FOR MORE PERFORMANCE: The redesigned rotor blades offer an optimal balance of performance and low noise – especially efficient at low speeds
